LS3 6.2 V8 – Chevrolet Corvette (C6), Camaro SS & HSV Head Gasket Keychain
This stainless-steel head gasket keychain celebrates the GM LS3, Chevrolet’s naturally aspirated 6.2-litre Gen IV small-block V8. First fitted to the 2008 Chevrolet Corvette, the LS3 combined an aluminium block, rectangular-port cylinder heads and 376 cubic inches of pushrod V8 performance.
Engine Identity
-
Manufacturer: General Motors / Chevrolet.
-
Engine code: LS3.
-
Engine family: Gen IV GM LS-series small-block V8.
-
Configuration: Naturally aspirated 90-degree V8 petrol engine.
-
Cylinder count: Eight.
-
Displacement: 6,162 cc / 6.2 litres / 376 cubic inches.
-
Production period: 2008–2017 in factory road-car applications.
-
Valvetrain: Cam-in-block overhead-valve design with two valves per cylinder, hydraulic-roller camshaft and 16 valves in total.
-
Fuel system: Sequential electronic port fuel injection; the LS3 is not a direct-injection engine.
GM Performance identifies the LS3 as an all-aluminium Gen IV small-block V8 with a cast-aluminium block, six-bolt cross-bolted main caps and aluminium L92-style rectangular-port cylinder heads.
Vehicle Compatibility Matrix
The LS3 should not be confused with the L99 Camaro automatic engine, which added Active Fuel Management and variable valve timing, or with the later direct-injection LT1.
Why This Engine Matters
The LS3 is one of the defining modern Chevrolet pushrod V8s because it delivered large-capacity naturally aspirated performance from a relatively compact and lightweight aluminium small-block package. It became the standard engine in the C6 Corvette and fifth-generation Camaro SS, two of Chevrolet’s most important modern performance cars.
Its rectangular-port L92-style cylinder heads, 10.7:1 compression ratio and hydraulic-roller camshaft give the factory LS3 strong airflow and a wide performance aftermarket. The engine’s absence of cylinder deactivation and variable valve timing in standard LS3 specification has also made it particularly recognisable among GM V8 enthusiasts.
Technical Specifications
Factory output varies by vehicle. Chevrolet Corvette LS3 versions were rated from 430 to 436 hp, while Camaro SS, Pontiac G8 GXP and Chevrolet SS calibrations differ by model year and exhaust system. The engine dimensions and core architecture above are drawn from Chevrolet Performance’s LS3 crate-engine technical specification, published on its New Zealand site in 2024.
Product Details
-
Stainless-steel head gasket keychain inspired by the GM LS3 6.2-litre small-block V8 cylinder-head gasket profile.
-
Designed for owners and enthusiasts of LS3-powered Corvette, Camaro SS, Pontiac G8 GXP, Chevrolet SS and Holden/HSV vehicles.
-
Finished using our three-stage vibratory polishing process for a smooth, durable metal finish.
-
Supplied on a plywood display card for gifting, collecting or display.
-
A compact tribute to Chevrolet’s 376-cubic-inch naturally aspirated Gen IV LS V8.
FAQ
What is a GM LS3 engine?
The LS3 is a naturally aspirated 6.2-litre, 6,162 cc Gen IV Chevrolet small-block V8 with an aluminium block, overhead valves and two valves per cylinder.
Which cars had the LS3 engine?
Factory LS3 applications include the 2008–2013 Chevrolet Corvette C6, 2010–2015 manual Chevrolet Camaro SS, 2009 Pontiac G8 GXP and 2014–2017 Chevrolet SS.
Is the Camaro L99 the same as an LS3?
No. The L99 is closely related to the LS3 but was fitted to automatic fifth-generation Camaro SS models and includes Active Fuel Management and variable valve timing, unlike standard LS3 specification.
Is this a functional replacement head gasket?
No. This is a decorative stainless-steel keychain inspired by the LS3 head-gasket shape; it is not an engine-service component.
